Description
Massey Ferguson MF 235 Agricultural Loader Operator’s Manual
44 Pages
This Manual is available in: Digital Download
CONTENTS
ASSEMBLY INSTRUCTIONS
- Preparing Tractor
- Assembling Loader To:
- MF 135 Tractor
- MF 150, MF 165, and MF 175 Tractors
- MF 180 and MF 1080 Tractors
- MF 1100 Tractor
HYDRAULICS
- Hydraulic Hose Installation
- 2-Spool Auxiliary Hydraulic Quick Couplers
- Auxiliary Hydraulic Control Valve Mounted on Tractor Lift Cover
- Loader Mounted Auxiliary Valve Installation
- Front Mounted Pump Installation
- MF 135 Tractor
- MF 165 and MF 175 Tractors
- Rear Mounted PTO Pump Installation – MF 135, MF 165, MF 175, and MF 180 Tractors
ASSEMBLING GRAPPLE FORK
ASSEMBLING PUSH-OFF STACKER
OPERATION
- Loader Control
- Tractor Internal Hydraulic System with Auxiliary Control Valve
- 2-Spool Auxiliary Control Valves
- 3-Spool Auxiliary Control Valves
- Tractor Independent Auxiliary Hydraulics with 2-Spool Auxiliary Control Valve
- Loader Frame Adjustments
- Operating Loader
- Detaching Loader
- Attaching Loader
LUBRICATION AND MAINTENANCE
- Lubrication
- Maintenance
TROUBLE-SHOOTING
SPECIFICATIONS
Manual Code: 1448 230 M4
