Massey Ferguson MF880 Moldboard Plow Operating Instructions

Description

Massey Ferguson MF 880 Moldboard Plow Operator’s Manual

40 Pages

This manual is available in: Digital Download

CONTENTS

OPERATION

• Preparing Tractor
• Wheel Spacing
• Wheel Weighting
• Front End Weights
• Dual Wheels
• Draft and Depth Intermix Kit (Accessory for MF 165, MF 175 and MF 180 Tractors)
• Stabilizer Bars — When Using Semi-Mounted Plows
• Check Chains — When Using Semi-Mounted Plows
• Lower Lift Links and Hydraulic Control Levers — When Using Pull-Type Plows
• Preparing Plow
• Land Wheel Hydraulic Cylinder — Pull-Type Plows
• Plow Bottoms
• Checking Plow Bottom Alignment
• Tire Pressures
• Tongue Positions
• Changing Tongue Position and Adjusting Steering
• Semi-Mounted — Rigid Hitch
• Semi-Mounted — Flexible Hitch
• Pull-Type
• Hitch Positions
• Hitch Turning Stop Assembly
• Attaching Plow to Tractor
• Semi-Mounted Plow
• Tractors with 3-point Hitch — MF 165 to MF 180
• Tractors with 3-Point Hitch — MF 1080 and Larger
• Tractors with Rapid Coupler — MF 165 and Larger
• Pull-Type Plow
• Universal Hitch
• Hydraulic Hook-Up
• Plows Equipped with Accumulator System
• Plows Equipped with Central Hydraulic System
• Checking and Charging Accumulator Nitrogen Supply
• Charging Accumulator Reset System
• Leveling Plow
• Semi-Mounted
• Rigid Hitch
• Flexible Hitch and Front Furrow Wheel
• Pull-Type
• Adjusting Plow Bottom Points
• Landside Adjustment
• Rear Bottom
• Front Bottom
• Gauge Wheel
• Front Furrow Wheel Land Opening Latch
• Width of Cut Adjustment
• Semi-Mounted
• Pull-Type
• Coulter Adjustments
• Spring Cushion and Shear Bolt Coulters
• Concave Coulter
• Trashboards
• Spring Trip Equipped Beams
• Shear Bolt Equipped Beams
• Trip Beam Adjustments
• Hydraulic Reset Beam
• Spring Trip Beam
• Shear Bolt Beam
• Spring Reset Beam
• Turning Plow
• Transporting
• Field Operation
• Semi-Mounted
• Pull-Type
• Changing Plowing Depth

PLOWING DIFFICULTIES AND CORRECTIONS

LUBRICATION

MAINTENANCE

• Torque Reference
• Plow Bottoms
• Shares
• Coulters
• Periodic Testing of Accumulator
• Storage
• Removing from Storage

ACCESSORIES AND VARIABLES

SPECIFICATIONS

Manual Code: 1448 205 M5
