Description
New Holland Super Hayliner 78 Baler Owner’s Manual
50 Pages
This Manual is available in: Digital Download
CONTENTS
GENERAL INFORMATION
- A note to you Baler Owner
- About improvements
- Introduction
- Contents
- Specifications
OPERATION
- Before using your baler
- Attaching the baler to the tractor
- Lubrication
- Jack
- Controls
- Tongue shift
- Belt tightener
- Throttle control
- Pickup lift
- Starting the baler
- Threading the baler
- Bale weight
- Bale length
- Tying
SAFETY FEATURES
- Flywheel shearbolt
- Knotter drive shearbolt
- Needle safety latch
- Pickup drive slip clutch and overriding clutch
- PTO drive slip clutch and overriding clutch
- Auxiliary drive shearbolt
ADJUSTMENTS
- Pickup wheel
- Windguard
- Pickup lift spring
- Knife adjustment
- Plunger bearing adjustment and slide
- Tine bar timing
- Needle drive timing
- Upper feed reel
- Tooth pitch
- Timing
- Drive chain
- Drive belts
- Bale shape
- Needles
- Twine fingers
- Knotter brake
- Metering wheel
- Bale counter
- Knotter
- Twine disc
- Twine holder
- Bill hook
- Knife arm
MAINTENANCE
- Service adjustment chart
- Engine care
- Main gearbox
- Tires
- Belts
- PTO
- Pickup fingers
- Pickup cam followers
- Storing the baler
- Safety precautions
- Overheating switch
- Special equipment
- Hydraformatic bale tension control
- Warranty
Manual Code: O78-2-3500-1-59W
