Self-Priming Jet Pressure Pump – Grundfos JP 3-42 PM1

Description

JP PM is a booster that consists of a pressure manager and a self-priming, single-stage centrifugal pump. JP PM is designed for various garden and domestic applications and has dry-running protection.

Technical

Rated flow3 m³/hRated head17.91 mCode for shaft sealBBVPApprovalsCE,EACCurve toleranceISO9906:2012 3BPump versionAModelAAdjustable start pressure (Yes/No)NStart pressure1.5 bar

Materials

Pump housingStainless steel
EN 1.4301
AISI 304ImpellerComposite
PPO-20GFMaterial codeA

Installation

Range of ambient temperature0 .. 40 °CMaximum operating pressurePN 6 barPipe connection standardISO 228-1Type of inlet connectionG(F)Type of outlet connectionG(F)Size of inlet connection1 inchSize of outlet connection1 inchPressure rating for connectionPN 6

Liquid

Pumped liquidWaterLiquid temperature range0 .. 40 °CSelected liquid temperature20 °CDensity998.2 kg/m³

Electrical data

Power input P1700 WRated power – P20.55 kWMains frequency50 HzRated voltage1 x 220-240 VRated current3.2 AStarting current13.2 ARated speed2850 rpmCapacitor size – run14 µF/450 VEnclosure class (IEC 34-5)IP44Insulation class (IEC 85)FLength of cable1.5 mPower plugSCHUKO

Controls

Type of connectorType E/F (CEE7/7)

Others

Net weight9 kgGross weight14 kgEnvironmental approvalsWEEE
