Farmall and International GSS-1010-B Diesel Tractor Fuel System Guide for D-236, D-282, and D-301 Engines

Description

Farmall and International GSS-1010-B Tractors Fuel System Diesel Engine Models D-236, D-282, and D-301 Blue Ribbon Service Manual

82 Pages

This Manual is available in: Digital Download

CONTENTS

Specifications

General Description and Operation

• Filter System
• Factors Affecting Pump and Nozzle Life
• The Injection Pump
• Load Advance
• Automatic Speed Advance (Later Model)

Injection Nozzles and Precombustion Chambers

Trouble Shooting

Checks and Adjustments

• Fuel Shut-Off Adjustment
• Governor Linkage Hook Adjustment
• High and Low Idle Speed Adjustment
• Governor Control Adjustment
• Transfer Pump Adjustments
• Air Leaks in Suction Side of Fuel System
• Inefficient Transfer Pump or Malfunctioning Pressure Regulating Valve
• Transfer Pump Pressure
• Fuel Return Line Plugged or Restricted
• Delivery Valve and Rotor Check
• Broken Delivery Valve Spring
• Pump Timing and Rotor Rotations
• Load Advance Adjustment
• Speed Advance Adjustment
• Glow Plugs
• Compression Pressure
• Torque Screw Adjustment
• Leaf-Spring Adjustment

Injection Pump Service

• Pump Removal
• Drive Shaft Removal
• Pump Disassembly
• End Plate Assemblies
• Inspection and Repair
• Reassembly
• Pump Drive Shaft and Injection Pump Installation

Injection Nozzle and Pre-combustion Chamber Service

• Bosch – Model ADE
• Removal
• Testing
• Preliminary Inspection
• Disassembly
• Inspection and Repair
• Reassembly and Testing
• Installation
• IH Midget or Micro Nozzles
• Disassembly
• Inspection and Repair
• Reassembly
• Testing
• Pre combustion Chambers

Priming Pump

Induction System Service

Special Service Tools

Manual Code: GSS-1010-B
