Massey Ferguson MF22 PTO Bale Thrower Setup and Operation Manual

Description

Massey Ferguson MF 22 PTO Bale Thrower Operator’s Manual and Assembly Instructions

28 Pages

This Manual is available in: Digital Download

CONTENTS

INTRODUCTION

ASSEMBLY Instructions

OPERATION

• Variable Equipment
• Preparing Baler
• Attaching Wagon to Baler

OPERATING ADJUSTMENTS

• Variable Pulley Cable Length
• Upper Belt Frame
• Tension Rod Springs
• Upper and Lower Belt Tension
• Clutch Tension Spring
• Gear Box “V” – Belt
• Guide Arm

OPERATING INFORMATION

• Engaging Bale Thrower
• PTO Bale Thrower Speed
• Control Post
• Bale Tension Handles
• Loading Trailing Wagon
• Hydraulic Steering Control

BALE THROWER DIFFICULTIES AND CORRECTIONS

PERIODIC MAINTENANCE

• Lubrication
• Maintenance
• Servicing

HYDRAULIC STEERING CONTROL FOR BALE THROWER

RESTRICTORS FOR HYDRAULIC SWING LINES

SPECIFICATIONS
