New Holland 87 Wire-Tie Baler Operating Guide

Description

New Holland 87 Wire Tie Baler Operator’s Manual

46 Pages

This Manual is available in: Digital Download

CONTENTS

About Improvements

Safety Precautions

Specifications

Before Using your New Baler

Lubrication

Standard Equipment

Break-In

Crop Preparation

Daily Check Points

Operation

• Hitching to Tractor
• Handling the Wire
• Installing the coil of wire
• in the wire container
• Wire Tension
• Threading the Wire
• Starting to Bale
• Replacing Wire Coils

Safety Features

• Flywheel Safety Bolt
• Gearbox Safety Bolt
• Ejector Safety Bolt
• Twister Drive Safety Bolt

Adjustments

• Belt In formation and Adjustments
• Care of Roller Chain
• Pick-Up Lift Spring
• Pick-Up Wheel
• Pick-Up Chain
• Feed Roll
• Wadboard and Feed Arm
• Plunger Roller Adjustments
• Slicing Knives
• Connecting Rod
• Bale Counter

The Operation of the Over-Center Assy

Adjustment of Over-Center Assembly

Twister Operation

The Twister (Explanation of)

• Disassembling the Twister
• Reassembling the Twister
• Re-lnsta1ling Twister Assembly
• Setting the Locator Roller
• Removing Backlash from the
• Twister Drive Shaft
• Ejector Timing
• Removing the Twister Guards
• Remounting the Twister Guards
• Wire Pick-Up Assemblies
• Needle Timing
• Wire Holder Cam Adjustment
• Wire Pick-Up and Carrier Pin
• Alignment
• Needle Adjustment
• Needle Brake
• Hydraformatic Bale Tension

Baler Maintenance

• Replacing Pick-Up Fingers
• Engine
• Main Drive Shaft Bearings

Storage of Baler

Instructions for Ordering Service Parts

Trouble Shooting

Model 87 P.T.O

Bull Gear-Pinion Mesh

Push Rod Bracket

Crank Pin Locations

Accessories

Warranty

Manual Code: 2133-2500-3-58W
